30w semi integrated street All-in-One Solar Street Lights

Share to:


For detailed product information, please click here.

ALIEN Series integrates solar panel, lithium battery, solar controller and LED modules as one unit. It is applied to 30w semi integrated street All-in-One Solar Street Lights.

Features_Allien-s All-in-one Solar Light_1

Compared with traditional All-In-One Solar Street Light, there are the following differences

Adjustable lighting source and solar panel
0-360° horizontally and -45°-+45° vertically adjustable lighting source together with 360° horizontally adjustable solar panel ensure optimal angle between solar panel and sunrays, thus the highest charging efficiency and best illumination effects.
Notes: how to achieve optimal angle between solar panel and lighting source.

A: Set solar panel to south (in south hemisphere, it should face north)

Features_Allien-s All-in-one Solar Light_2

B: Adjust lighting source horizontally and vertically according to direction of roads.

Features_Allien-s All-in-one Solar Light_3

Notes: Multi-light solutionsfor area lighting

Modular design makes additional lighting source and different illuminating directions available, which is especially suitable for large areas with multiple targets to be illuminated.

Features_Allien-s All-in-one Solar Light_4

No Back Plate Design

Better heat dissipation performance
With back plate, heat accumulated under conventional solar panel is hard to dissipated, which will lead to high operation ambient temperature, thus significantly reduce the service life of electronic components.
Insects and dusts prevention

In desert or tropic areas, dusts and insects will find the thermal dissipation hole a very easy access into the lamp housing, whose accumulation will then impede the heat dissipation of whole system.

Features_Allien-s All-in-one Solar Light_5

Work at All Climates

With LiFePO4 battery's high-temperature resistance, controller's temperature compensated function and BMS' temperature protection system, ALIEN series is able to operate under extreme climate conditions.

Features_Allien-s All-in-one Solar Light_6



Model No. INL-AIO5-S
Lamp Lumen & Power 3625lm 4350lm 7400lm 8900lm 10500lm 12040lm
(30W) (40W) (60W) (80W) (100W) (120W)
Solar Panel Capacity 40W 50W 70W 90W 100W 120W
LiFePO4 Lithium Battery 230WH 256WH 384WH 512WH 640WH 768WH
Product Dimension

Mounting Height 3-6 4-7 5-8 6-9 7-10 8-12
Meters Meters Meters Meters Meters Meters
System Life Span > 10 years
Optional Functions motion sensor / IOT smart control system/CCTV Camera
All above parameters can be customized.
Smart Lighting Mode
Falcon Series offers various lighting working modes with different programs available.
Working Time up to 14 hours per night
Autonomy Days Backup up to 7 days depending on lighting mode
Specifications_Allien-s All-in-one Solar Light

Optional parts

Optional Parts_Allien-s All-in-one Solar Light_1
Optional Parts_Falcon All-in-two Solar Light_2
Optional Parts_Allien-s All-in-one Solar Light_2
Optional Parts_Falcon All-in-two Solar Light_4


Plug & Play Solution replaces switches, which makes installation much easier and is more durable than switches.

Installation_ALLIEN All-in-one Solar
