Iluminação do distrito comercial
Design safe, attractive lighting for commercial streets and business districts—aligned with EN 13201 e IES RP-8. We apply baseado em luminância design on vehicular lanes and illuminance with vertical/semicylindrical metrics along storefronts and pedestrian frontages. Optics, mounting height and spacing are optimized from photometry to deliver uniformity and low glare, while BUG/TM-15 limits spill near residences and skylines. Typical 3000–4000 K supports comfortable ambience. Send your plan for a standards-compliant layout, calculation report and bill of materials—available in LED alimentado pela rede ou solar options.
Key Considerations for Business District Lighting
Standards alignment
EN 13201 (M/P/SC) and IES RP-8 for mixed traffic–pedestrian frontages.
People-facing light
Add vertical/semicilíndrico components on storefronts, entries and transit nodes.
Comfort & ambience
3000–4000 K typical in CBDs; warmer near residences/waterfronts.
Glare & spill — Control BUG/TM-15 and veiling glare; shield near perimeters and upper stories.
Glare & spill
Control BUG/TM-15 and veiling glare; shield near perimeters and upper stories.
Energy & O&M
Scheduling and occupancy sensors; for solar, autonomy sized for worst-case nights.
Mounting strategy
Roadway poles for carriageways; post-tops/pedestrian poles/bollards for sidewalks & plazas.
Design Principles for Business District Lighting
Methods & classes
M-class luminance on vehicular lanes; P-class with vertical/SC along pedestrian frontages, entries and façades; verify uniformidade and manage disability glare.
Optics & geometry
Tipo II/III for streets; post-tops/Type IV/V for sidewalks & plazas; spacing is a calculation outcome based on targets, photometry and mounting.
Color & perception
3000–4000 K com CRI ≥70/80; raise vertical components at key nodes and CCTV areas.
Spill & skyline
Control backlight and uplight per BUG/TM-15 to reduce trespass and sky glow.
Controls
Time-of-day dimming and scene presets; solar options with MPPT, autonomy days and surge protection.
Soluções por cenário
Commercial Arterials & Avenues
Luminance-based layouts for lanes with low glare and consistent driver adaptation.
Pedestrian Frontages & Storefronts
Added vertical/SC components for recognition, wayfinding and CCTV clarity.
Entries, Plazas & Pocket Squares
Comfortable horizontal light with enhanced verticals on faces and façades.
Transit Entrances & Drop-offs
Targeted vertical light on entries, signage and queuing areas for visibility and safety.
Service Alleys & Loading Bays
Robust optics and vertical light for cameras and maneuvering; spill-aware near residences.
(Optional) Parking & EV Islands
Uniform area lighting with controlled spill and clear guidance at chargers.
O que você recebe
- EN 13201 / IES RP-8 compliant layout (luminance or illuminance/vertical/SC as applicable)
- Arquivos fotométricos (IES/LDT) + relatórios de cálculo
- Pole/foundation drawings + single-line diagram
- Bill of materials with options (LED vs Solar, pole heights, optics)
- O&M and warranty checklist
- Compliance crosswalk mapping local guidelines to EN 13201 / IES RP-8.
- Lead time, logistics and installation method statement (optional).
Produtos recomendados para iluminação pública solar
FALCON (INL-AIT6)
Saída média, ótica versátil, instalação rápida - ideal para ruas, caminhos e lotes.
SIRIUS (INL-AIO9)
High-output SIRIUS (INL-AIO9) with adjustable head, Type II/III optics, 7070 LEDs and LiFePO4—built for two-way roads and highways.
Bateria de lítio APOLLO
Sistema do tipo dividido com armazenamento LiFePO4, LEDs 5050, telemetria inteligente/de movimento opcional; painel e ângulos de lâmpada flexíveis para maximizar o rendimento e a cobertura de ruas, caminhos e estacionamentos.
Solar AC Híbrido
Iluminação solar com backup inteligente de CA para garantir a operação noturna durante as estações de baixo isolamento ou redes instáveis; ideal para vias expressas de aeroportos e corredores municipais.
INL-SPL01 - Luz solar vertical para poste
Vertical PV wrapped around the pole with All-in-Two light engine. 30–150W LED, IP66/IK09, 6–12 m mounting, Type II/III optics. Clean look, easy maintenance, project-ready.
Produtos recomendados para iluminação pública de LED
Descubra nossas soluções de iluminação pública de LED projetadas para cenários de iluminação de parques e recreação. Todos esses produtos podem ser personalizados de acordo com os requisitos das especificações de seu projeto.
INL-LED25 - Luz de rua de LED
Pacotes de 100-200 W, óptica de estrada e drivers prontos para controles para estradas principais e coletoras.
INL-LED24 - Luz de rua de LED
50-200 W com óptica precisa Tipo II/III/V; serviço sem ferramentas e opções de SPD para municípios.
INL-LED23 - Luz de rua de LED
Faixa de alta potência de 50-240 W para espaçamentos mais amplos; vários suportes de braço/slip-fitter.
INL-LED22 - Luz de rua de LED
Plataforma versátil de 60-200 W com opções de controles e distribuições de pista.
INL-LED13 - Luz de rua de LED
60-200 W com invólucro fundido durável e classificações IP/IK para ruas e lotes urbanos.
