High Mast Light

High mast lighting system is a type of site light fixture that is commonly used to illuminate large areas from a very high mounting height for ports, parking lots, squares, storage zones, airports, etc. High mast fixtures ar are typically mounted on poles 15 meters to 50 meters tall.


Features
Structure
Specifications
Flood Lights
Mast Pole
DIALX Simulation
Installation
Applications

Features

External Design Features

Structure

External Design Features

Specifications

Lamp Wattage

50W – 2000W

Lamp Qty

2 – 30sets

Lamp Working Voltage

90-305V / 249-528V AC, 50/60HZ

Power Supply

MOSO / MEANWELL / PHILLIPS

Luminous Efficiency

120-200lm/w (3030 LEDs)  / 150-200lm/w (5050 LEDs)

CCT

3000K/4000K/5000K/6000K

Pole Height

12 - 40 meters

Pole Material

Q345B/A572,minimum yield strength>=345n/mm2

Q235B/A36,minimum yield strength>=235n/mm2

Joint of Poles

insert mode, inner flange mode, face to face joint mode

IP/IK Rate

IP66 / IK10

Wind Resistance Capacity

120km/h

Life Time

> 25 years

Accessories

raising and lowering system, lighting rod


Flood Lights

Flood Lights of High Mast Light


LED Flood Light Specifications


Model

INL-FD5

INL-FD6

Power Range

50W- 600W

300W-1000W

Power Supply

MOSO / MEANWELL / PHILLIPS /INVETRONICS

Working Voltage

90-305V/249-528V AC , 50/60HZ

Lighting Source

3030 LED / 5050 LED

3030 LED

Luminous Efficiency

>130lm/w (3030 LED) , >175lm/w (5050 LED)

>130lm/w

CCT

3000K/4000K/5000K/6000K

Beam Angle

TypeⅠ,Ⅱ,Ⅱ-Vertical,Ⅲ,Ⅳ,Ⅴ

IP/IK Rate

IP66/IK10

IP65/IK09

Lifespan

>50,000 Hours

Working Temperature

-40°C~65°C, 20%~90%  RH



LED Flood Lighting Distribution


LED Flood Lighting Distribution


Solar Components


Solar Components


Brand

PHILLIPS

YAMING

Power Range

250W /400W / 600W / 1000W

Lighting Source

High-Pressure Sodium (HPS)

Working Voltage

100-277V, 50/60HZ

IP/IK Rate

IP65/IK08

Working Temperature

-40°C~65°C, 20%~90%  RH


Mast Pole

The Polygonal Mast Pole comprises multiple sections of tapered poles formed by bending steel plates. The Polygonal Mast Pole can be installed on-site by socketing the pole sections together without any extra welding. The inner and outer sides of the Poles are integrally hot-dip galvanized to resist corrosion and have a service life of more than 30 years. The reinforced waterproof Inspection Door is located at the bottom of the light pole for easy access to equipment. It is equipped with two heavy-duty locks to prevent illegal operations. The base of the pole is fixed with Foundation kits fixed in the concrete foundation, which can withstand hurricane winds of 160km/h.


Welding

No crack, no leakage welding or bite edges. Smooth welding without the concavoconvex fluctuation or any welding defects.


Welding

Hot Dip Galvanizing

Inside and outside surface anti-corrosion treatment by hot dipping acid. Zinc coating is more than 80 um thick, which is in accordance with GB/T13912-92 standard. And the galvanized surface is smooth and with the same color. Flake peeling doesn’t exist after maul test.

Hot Dip Galvanizing


Powder Coating (Optional)

Strong adhesion & strong Anti-ultraviolet. The surface is not peeling even with blade scratch (smooth, color and luster are identical.)

Powder Coating (Optional)

DIALX Simulation

Whether you plan to light up an open-air warehouse, a plaza, a port, an airport, a street, or any other environment, our team of experienced lighting professionals will work closely with you to understand your needs and provide the optimal lighting solution. We offer professional photometric analysis and DIALUX simulation reports for each project. We create accurate 3D models of your space and simulate lighting effects in real-time, allowing you to visualize different lighting scenarios, adjust parameters, and fine-tune the design to achieve your desired lighting effects.

High Mast Light DIALX Simulation

Installation

Installation of High Mast Light

Applications

Applications of High Mast Light
POWER YOUR FUTURE, LIGHTENING TOMORROW

Our experienced professional sales engineers wil assist you with solar street light price quotations and technical proposals according to your specific project requirements.
